This 3861 Series Directional LED Light has red LEDs, polycarbonate housing with encapsulated electronics, 7 flash patterns, & an oval grommet mount. It is 2.2" high, 6.5" wide, 1.2" deep, 0.26 amps, & is compatible with 12-24V DC.

---

The 3800 Series directional LEDs are compact, LED warning lights suitable for mounting anywhere on a vehicle. Colorless until illuminated, these discrete, LED light heads feature encapsulated electronics offering a high degree of environmental and vibration protection. Additional benefits of ECCO’s directional LEDs include single and dual-color options, low-current draw and a long and maintenance-free service life. The LED light heads operate at 12-24 volts and have multiple, user-selectable flash patterns.

• Directional LED: Oval grommet mount, 12-24VDC, 7 flash patterns, red

---

Information:

Directional LED; Red; 12-24V DC; 0.26 amps; Oval Grommet Mount; 2.2" height; 6.5" width; 1.2" Depth; SAE Class I; Tough, clear polycarbonate housing with encapsulated electronics; Seven flash patterns for single-color and 41 flash patterns for dual-color; Synchronizable with additional 3811/3861; Discrete units are colorless when not illuminated; Grommet-mount versions fit standard oval rear lighting grommet; Temperature Range:-40°F to +158°F (-40°C to +70°C); Accessories: PN: 3860ADPT Grommet, PN: A9895 Oval Grommet Mounting Box, PN: R2160GO Oval Grommet.

Attributes
Category	Automotive Lighting
Emission Code	Legal US
Hazardous Material Code	N
Life Cycle Status Code	Available to Order
Series	Directional LED Auxiliary Lights
Subcategory	LED Auxiliary Lights
Warranty Time	36
